3DFM IN718 Inconel Powder
Shipping estimation
HK Post/DHL Air Delivery-5-8 working days:($0.00)
New product
This inconel 718 powder are compatible with 3D printer technologies such as SLM，SLS，Laser Cladding, EBM and other 3D printers using powder as print material.
Intro
This titanium powder is a powder that is specially optimized for shaping objects in SLM technologies, this includes the company EOS Selective Laser Melting technology, for example the EOSINT M series. Further is Arcam series, ConceptLaser series, Renishaw series, 3Dsystems Series and other companies with selective laser melting technology or EBM (Electron Beam Melting) technology.
Buying Requirements
Material and spherical size can be tailored according to your demand. Material and production process are all patented and approved for commercial use.
Order will be custom made as we do not have this in stock for immediately shipment.
Minimum Order Quantity is: 20 KG per order.
Sample can be provided (varies from 500 gram to 2KG). Please checkout with sample, freight is included in the price.
Price is not including shipping cost when order none sample. You will get a seperate invoice for shipping. For big orders we or you can arrange boat shipment.
(Estimated shipping cost is 15-25 USD/KG to EU and USA through air)
"Please contact us before making any order! "
We offer most of the materials available in the market, please contact us and we will establish the product at the store.
Summary
Together with our manufacturer we can offer you most of the materials available in the market for 3D printing.
This IN718 Inconel 3D printing powder and its preparation method and application is patented and approved for commercial use. The product we offers are in strict accordance with the ISO9001 quality assurance system for production and manufacturing.
Compatibility
SLM, SLS, Laser Cladding, EBM and other technology based on the same functionality.
Internal Quality System Certification Data
|
Internal Quality System Certification Data |
|
|
Chemical composition |
Ni (50.0-55.0 wt-% ) |
|
Nb (4.75 – 5.5 wt-%) |
|
|
Ti (0.65-1.15 wt-%) |
|
|
Mn,Si ( each 0.35 wt-%) |
|
|
P,S ( each 0.01 wt-%) |
|
|
Cu (<0.3 wt-%) |
|
|
Cr (17.0-21.0 wt-%) |
|
|
Mo (2.8-3.3 wt-%) |
|
| Al (0.2-0.8 wt-%) | |
| O (< 800 ppm) | |
| C (< 800 ppm) | |
|
Density |
8.15 g/cm³ |
|
Granularity |
-250 |
|
Sphericity |
≥93.0 % |
|
Recommended thickness |
30, 40 μm |
|
Bulk density |
59.0% |
|
Relative density of formed parts |
Close to. 100 % |
Close up powder illustrated as follows (SEM)
Formed parts mechanical properties
|
Powder Rapid Prototyping Parts Related Indicators |
||
|
|
As built |
After age hardening |
|
Typical achievable part accuracy |
|
|
|
- small parts (< 80 x 80 mm) |
-approx. 50 μm |
|
|
- large parts |
-approx. 80 μm |
|
|
Surface roughness |
|
|
|
- as manufactured |
-Ra 6 - 15 μm, Rz 50 – 70 μm |
|
|
- after shot-peening |
-Ra 3 - 5 μm, Rz 13 – 34 μm |
|
|
- after polishing |
-Rz up to < 0.2 μm |
|
|
Ultimate tensile strength (include horizontal and vertical direction) |
typ. 1000±40 MPa |
typ. 1280±80 MPa |
|
Yield strength (Rp 0.2 %) |
typ. 680±50 MPa |
typ. 1080±70 MPa |
|
Elongation at break (include horizontal |
typ. (28 ± 5 ) % |
typ. (13 ± 4) % |
|
Hardness |
Typ. 31 HRC |
Typ. 46 HRC |
|
Thermal conductivity |
Approx. 650 °C |
|
Parts Printed with this material
Article Size Distribution
N/A
| This Product Ships from | China |
| Compositions/Materials | Inconel |
Reviews (0)
Only registered users can post a new review.
Show reviews in my language
Questions Asked(total:1)
Hi,
We are would like to try out 3D printing with Inconel and would like to purchase 300-500g of this Inconel 718 powder (grain size
